Size: 45x45x10mm (1.77x1.77x0.39inch)
Frame: Plastic UL94V0
Impeller: Plastic UL94V0
Lead Wire: UL1571AWG#28 or Equivalent (+) Red, (-) Black
Bearings: C=Ball Bearing
Life Expectancy: 70,000Hours at 20℃-Ball.
Temperature Range: Temperature Range
Operating: Temperature -10*C~70'C (Non-condensing)
Storage Temperature: -40'C~70'C (Non-condensing)
Approvals: CE, RoHS
DC FAN Specials: RD, FG, PWM
Rated Voltage: 12V Noise: 66.20~71.20dBA
Rated Current: 1.24~2.01A Rated Input Power: 14.88~24.12W
Speed: 17500~24000RPM Air Flow: 31.83~37.76CFM
Weight: 101.0g Mounting: Free Standing
| Model | Bearing System | Rated Voltage | Operating Voltage | Current | Input Power | Rated Speed | Air Flow | Air Pressure | Noise | Weight | |||
| Part No. | S | C | VDC | VDC | A | Watt | R.P.M | CFM | inch-H20 | mm-H20 | dBA | g | |
| FD04510#5H | √ | √ | 5 | 3.5~5.5 | 0.25 | 1.25 | 8000 | 6.20 | 0.15 | 3.81 | 29.8 | 10.0 | |
| FD04510#5M | √ | √ | 5 | 3.5~5.5 | 0.18 | 0.90 | 6000 | 4.46 | 0.08 | 2.03 | 23.5 | 10.0 | |
| FD04510#5L | √ | √ | 5 | 3.5~5.5 | 0.12 | 0.60 | 4000 | 2.79 | 0.04 | 1.02 | 21.0 | 10.0 | |
| FD04510#12H | √ | √ | 12 | 7.0~13.8 | 0.18 | 2.16 | 10000 | 7.51 | 0.21 | 5.33 | 34.5 | 10.0 | |
| FD04510#12M | √ | √ | 12 | 7.0~13.8 | 0.14 | 1.68 | 8000 | 6.20 | 0.15 | 3.81 | 29.8 | 10.0 | |
| FD04510#12L | √ | √ | 12 | 7.0~13.8 | 0.10 | 1.20 | 6000 | 4.46 | 0.08 | 2.03 | 23.5 | 10.0 | |
| All DC brushless cooling fan models could be customized on voltage or any other requirements to fit your need. | |||||||||||||
